XF028-A-00
Apllication for accommodations with required fire rating 60,meet watertight requipments.

clear size HxW	opening size of bulkhead	leaf size H1xW1	leaf thickness T	qty of clips
1200x600	1275x675	1300x700xR150	8	6
1400x600	1475x675	1500x700xR150	8	6
1500x600	1575x675	1600x700xR150	8	8
1600x600	1675x675	1700x700xR150	8	8
1600x700	1675x775	1700x800xR150	8	8
1700x600	1775x675	1800x700xR150	8	10
1700x700	1775x775	1800x800xR150	8	10
1800x600	1875x675	1900x700xR150	8	10
1800x700	1875x775	1900x800xR150	8	12
1800x800	1875x875	1900x900xR150	8	12
2000x1200	2075x1275	2100x1300xR1500	8	18

water pressure：0.03-0.1Mpa。
Identification example：
A60 steel watertight door with clear size of 2000x1200mm:A60 steel watertight door 2000x1200 XF028-A-00-1
